TELECAMERA MOTORIZZATA – PTZ – 20X – SDI – HDMI -FULLHD

 45,00 Prezzo unitario massimo i.e.

Disponibile a noleggio presso la sede di Brescia

TELECAMERE MOTORIZZATE PTZ, uscita HDMI e SDI3G, controllo over IP sia da pc che da joystick

Per conferenze, riunioni, presentazioni, webinar, broadcasting, streaming & co.

Qualora non riuscissi a noleggiare l’articolo o volessi ulteriori informazioni mandaci un messaggio rapido cliccando sul logo WhatsApp in basso a destra, oppure scrivi a: info@blackstarservice.it – o chiama il nostro tecnico Marco al 3201169791 – o la nostra sede allo 0305407891

By Black star service srl

Day based pricing : 104 ptz cam
45,00 / days
Data di ritiro
Data di Riconsegna
Quantita’
Quantità Prezzo scontato
2 - 2 39,15
3 - 3 36,00
4 - 4 31,50

 45,00 Prezzo unitario massimo i.e.



Lo sconto “noleggio più giorni” viene calcolato in questa pagina, mentre lo sconto “quantità” viene calcolato in fase di checkout

Tutti i prezzi esposti sono al netto dell’iva

L’inoltro della richiesta non comporta nessun obbligo di acquisto

LA TELECAMERA MOTORIZZATA PTZ - CON USCITE SDI E HDMI ZOOM 20X - CONTROLLO IP - VIENE FORNITO A NOLEGGIO CON SCAOTLA E CAVI

CONTROLLER OPZIONALE

1

RGBLink PTZ Camera 20x Optical Zoom; PTZ camera with 20x optical zoom; high quality 1/2. 8'' CMOS sensor; fast, silent rotation and panning; video output via HDMI, 3G-SDI or IP streaming via LAN with up to 1080p60; first-class image quality with rich colours even in low-light conditions; fast autofocus; can be put into operation immediately with the standard settings; Camera is easily configured via password-protected web browser access; Well-structured menu navigation allows audio, video and network parameters to be adjusted and firmware updates to be performed; Numerous image settings such as focus, exposure, colour space, gamma etc. can be changed from auto mode to personal preferences and saved; video signal output with 720p, 1080i or 1080p; optionally, date, time and the individual camera name can be superimposed on the image; an external audio source or microphone can be connected via the 3.5 mm stereo input, the audio signal is automatically embedded; the remote control supplied can control up to four RGBlink PTZ cameras and also adjust the most important parameters; integrated in a network, control is done via the web browser tool, at the same time the video stream is displayed on the PC monitor, allowing easy image control; compatible with external control devices supporting VISCA protocol or RS232; via the Xpose software on PC, Mac or smartphone; can simultaneously output two streams with different network protocols, codecs, resolutions and frames; creates streams using RTMP, RTSP, SRT or RTP protocol; videos can also be streamed directly to the internet and played back by appropriate hardware or software, e.g. via OBS-Studio; Technical data:; Optical zoom: 20x f = 3.3 ~ 110 mm; Angle of view: 3.3° tele / 54.7° wide angle; Aperture: F1.6 - F3.5; Connections:; 3G-SDI and HDMI output / Network 100 MBit / RS232 In and Out / RS485 In / Stereo Audio in 3.5 mm; Output signals: HDMI/SDI SMPTE - 720p@25/29.97/30/50/60 | 1080i@50/59.94/60 | 1080p@25/30/50/59.94/60 (Supports vertical and horizontal flipping of the image); Pan range: +/- 170° Pan / -30° to +90° Tilt; Variable speed from 0.1° up to 80° per second; Up to 254 memory locations for different viewing angles; Video Codecs: H.264, H.265 (dual stream output); Audio compression: AAC, MP3, PMC up to 128 Kbps; Control Protocol: VISCA/Pelco-D/Pelco-P; Baud Rate: 115200 / 9600 / 4800 / 2400 bps; Network Protocol: RTSP, RTMP, ONVIF, GB/T28181; Supported formats: HDMI 1.3 / SDI SMPTE 425M (Level A & B) / SMPTE 424M / SMPTE 292M / SMPTE 259M-C / DVB-ASI; Input voltage: DC 12 V / 1.5 A; Max. power consumption: 12 W; Dimensions: 150 x 150 x 168 mm; Weight: 1.4 kg; Included in delivery: 1 x RGBlink PTZ camera 20x Optical Zoom / 1x IR remote control / 1x 230V power supply

PDF

Connectors Video Output
HDMI 1xHDMI-A
SDI 1xBNC
Audio
Input 1x3.5mm mini-Jack
Communication
Network/LAN 1xRJ45
RS232 2xDIN-8
RS485 1x2way Terminal Connector
Power
1×HEC3800 DC Socket
Performance Camera
Optical Zoom 20x f=5.5~110mm

12x f=3.9~46.8mm

Digital Zoom 10x
Viewing Angle 20x 3.3°~ 54.7°

12x 6.3°~72.5°

AV 20x f1.6 ~ f3.5

12x f1.8~f2.4

Illumination Min 0.5 lux (F1.8, AGC ON)
Noise Reduction (DNR) 2D & 3D
White Balance Auto | Manual | One Push | 3000K | 3500K | 4000K | 4500K | 5000K | 5500K | 6000K | 6500K |7000K
White Range (WDR) OFF | Dynamic
Focus Auto | Manual
Aperture / Shutter Auto | Manual
BLC ON | OFF
Adjustments Brightness | Color | Saturation | Contrast | Sharpness | B/W | Gamma Curve
SNR >55dB
Pixels 2.07m, 16:9
Positioning
Movement Pan: -170°~+170°

Tilt: -30°~+90°

 Speed Pan: 0.1sec ~60°

Tilts: 0.1sec~30°/S

Presets Up to 255
Output Resolutions SDI | HDMI

720p25/29.97/30/50/59.94/60 | 1080p25/30/29.97/30/50/59.94/60

H.264 | H.265

720p25/29.97/30/50/59.94/60 | 1080p25/30/29.97/30/50/59.94/60
Standards Supported
SDI SMPTE 425M (Level A & B) | SMPTE 424M | SMPTE 292M | SMPTE 259M-C | DVB-ASI
HDMI 1.3
IP Streaming H.264 | H.265
Audio AAC | MPEG3 | G.711A
PTZ Control VISCA | Pelco-D | Pelco-P
Network RTSP | RTMP | ONVIF | GB/T28181 | VISCA
Power Input Voltage DC12V/1.5A (via Plug Pack supplied)
Max Power 12W
Environment Temperature -10℃~50℃
Humidity 20%~80% RH
Physical Weight
Net (device) 1.4kg
Dimensions
Net (device) 150mm x 150mm x 167.5mm
